1844440000 | Weidmüller

Socket header, 24 pole, pitch 5.08 mm, straight, black, 1844440000

Order No.: 50P5185
EAN: 4032248356379
MPN:
1844440000
BLT 5.08HC/24/180F SN BK BX
1844440000 Weidmüller PCB Connection Systems Image 1
1844440000 Weidmüller PCB Connection Systems Image 2
1844440000 Weidmüller PCB Connection Systems Image 3
Image may differ
Unit Price (€ / pc.)
34.3553 € *
Available in 6 Days: 60 pcs. - if ordered today
Total Price:
34.36 € *
Price list
Quantity
Price per unit*
1 pcs.
34.3553 €
10 pcs.
32.2014 €
25 pcs.
30.3093 €
50 pcs.
28.6314 €
*incl. VAT plus shipping costs
Subject to prior sale

PCB plug-in connector, 1844440000, Weidmüller

Female plugs with TOP screw connection system for connecting wires with straight outlet direction and screw flange. The female connectors provide space for labelling and can be coded.

Technical specifications
Filter Property Value
Connection clamp connection
Colour black
Pin number 24 pole
Contact type socket
Orientation straight
Rated voltage 400 V
contact surface tin-plated
Version socket header
Rated current 27 A
Number of rows 1
Grid 5.08 mm
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
RoHS conform Yes
SVHC free No
Date of RoHS guidelines 3/31/15
