1425700000 | Weidmüller
Pin contact, 0.34-0.5 mm², AWG 22-20, crimp connection, tin-plated, 1425700000
Order No.: 51P3171
EAN: 4008190175016
MPN:
1425700000
CSL1,6E22-20 SN I2,5
Unit Price (€ / pc.)
0.8330 € *
Available: 0 pcs.
Available in 6 Days: 1,250 pcs.
Leadtime: On Request **
Total Price:
0.83 € *
Price list
Quantity
Price per unit*
2 pcs.
0.8330 €
1250 pcs.
0.7616 €
6250 pcs.
0.6783 €
*incl. VAT plus shipping costs
**Subject to prior sale
Pin contact, 1425700000, Weidmüller
The 1425700000 is a pin contact standard. This product enables custom adaptations to the specific requirements of your applications.
Features
- Safe centring of the contacts using the three-segment pin tips
- High contact reliability using four defined contact points
- Locking clasp in the cantilever spring for a secure mount of the contacts in the housing
- Pin contacts with two lengths to implement leading-pin contacts
Technical specifications
| Version | pin contact | |
| AWG cross-section | AWG 22-20 | |
| Insulation diameter | 2-2.5 mm | |
| Contact connection | crimp connection | |
| Contact material | brass | |
| contact surface | tin-plated | |
| Cable cross-section | 0.34-0.5 mm² |
Download
Logistics
| Country of origin | NL |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
