243-747 | WAGO
Socket terminal block, 7 pole, 0.5-1.0 mm², clamping points: 28, light green, clamp connection, 6 A, 243-747
Unit Price (€ / pc.)
2.6894 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
2.69 € *
Price list
Quantity
Price per unit*
1 pcs.
2.6894 €
10 pcs.
2.4752 €
50 pcs.
2.2491 €
100 pcs.
2.0230 €
*incl. VAT plus shipping costs
Subject to prior sale
Connector, 243-747, WAGO
4-conductor female plug, PUSH WIRE, 0.8 mm Ø, pin spacing 5.75 mm, 7-pole, for individual solder pins, light green.
Features
- Four entries for power supply and potential distribution
- Push-in termination of solid conductors
- Quick and easy PCB replacement, without disrupting looped-through potentials
Technical specifications
| Version | socket terminal block | |
| Pin number | 7 pole | |
| Cable cross-section | 0.5-1.0 mm² | |
| Number of terminals | 28 | |
| Colour | light green | |
| Connection | clamp connection | |
| Rated current | 6 A | |
| AWG cross-section | AWG 24-18 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
