771-9994/206-101 | WAGO

Connection cable, 1 m, plug, 4 pole straight to open end, 1.5 mm², 771-9994/206-101

Order No.: 45P4042
EAN: 4044918273411
MPN:
771-9994/206-101
Series: WINSTA MIDI
771-9994/206-101 WAGO Pre-assembled Connector Systems Image 1
771-9994/206-101 WAGO Pre-assembled Connector Systems Image 2
Image may differ
Unit Price (€ / pc.)
9.8175 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
9.82 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
9.8175 €

Connecting line, 771-9994/206-101, WAGO

WINSTA MIDI Connecting line for power and signal transmission. The mechanical coding and color coding of the pluggable installation connector ensure error-free installation of the individual components - including protection against mismating. The pluggable installation connector is protected in accordance with protection type IP20. Through its Push-in Cage Clamp spring pressure connection technology, it achieves time-saving, error-free installation and offers customization and flexibility for meeting all installation requirements.

The WINSTA Pluggable Connection System is ideally tailored to the very strict requirements of building installation. It makes electrical installation pluggable, and consequently faster, even more reliable, and error-free. Using this pre-assembled system reduces assembly times and installation errors at the construction site.

Features

  • Protection against mismating eliminates errors
  • With A coding for use in many general mains applications
  • Ready for immediate use
  • Quick replacement of defective units during ongoing operation
Technical specifications
Cable length 1 m
Version connection line
Cable cross-section 1.5 mm²
Connection 1 design straight
Connection (2) open end
Connection (1) plug, 4 pole
Coding A
Logistics
Country of origin DE
Customs tariff number 85444290
Compliance
SVHC free No
Date of RoHS guidelines 3/31/15
RoHS conform Yes
