805-308/200-604 | WAGO
PCB terminal, 8 pole, pitch 3.5 mm, AWG 24-16, 17.5 A, push-in cage clamp, black, 805-308/200-604
Unit Price (€ / pc.)
2.2610 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
2.26 € *
Price list
Quantity
Price per unit*
1 pcs.
2.2610 €
10 pcs.
2.0349 €
*incl. VAT plus shipping costs
Subject to prior sale
THR PCB terminal block, 805-308/200-604, Wago
THR terminal strip with actuation pushers 1 solder pin/pole offset 8-pole grid dimension 3.5 mm / 0.138 in with actuation pushers without test opening black
Technical specifications
| Colour | black | |
| Depth | 13.6 mm | |
| AWG cross-section | AWG 24-16 | |
| Rated current | 17.5 A | |
| Grid | 3.5 mm | |
| Width | 29.5 mm | |
| Height | 13.7 mm | |
| Cable cross-section | 0.2-1.5 mm² | |
| Pin number | 8 pole | |
| Connection | push-in cage clamp | |
| Rated voltage | 320 V |
Download
Logistics
| Country of origin | CH |
| Customs tariff number | 85369010 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
