769-104 | WAGO
Socket header, 4 pole, pitch 5 mm, straight, gray, 769-104
Unit Price (€ / pc.)
4.4268 € *
Next delivery: 50 pcs. on 2025-09-25
Total Price:
4.43 € *
Price list
Quantity
Price per unit*
1 pcs.
4.4268 €
10 pcs.
4.0698 €
50 pcs.
3.7009 €
100 pcs.
3.3320 €
*incl. VAT plus shipping costs
Subject to prior sale
1-Conductor female connector, 769-104, Wago
1-conductor female connector, straight, for insertion into base terminals or pin headers, can be coded, bridgeable with mini cross-bridges, 4-pin gray
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5 mm | |
| Pin number | 4 pole | |
| Colour | gray | |
| Contact type | socket | |
| Rated current | 32 A | |
| Version | socket header | |
| Connection | spring-cage connection | |
| Additional parts | equipped | |
| Rated voltage | 500 V | |
| Orientation | straight |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
