Pin header, 7 pole, pitch 7.5 mm, angled, light gray, 721-867/001-000
Unit Price (€ / pc.)
2.1063 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Total Price:
2.11 € *
Price list
Quantity
Price per unit*
1 pcs.
2.1063 €
10 pcs.
1.9040 €
100 pcs.
1.7017 €
*incl. VAT plus shipping costs
**Subject to prior sale
Male header, 721-867/001-000, Wago
Male connector with straight solder pins 1,2 x 1,2 mm 7 poles Spacing 7,5 mm / 0.295 in 100 % mismating protected without leading PE-contact with side panels mating direction parallel to PCB light grey
Technical specifications
| Connection | solder pin | |
| Connection plating | tin-plated | |
| Number of rows | 1 | |
| Version | pin header | |
| Colour | light gray | |
| Contact type | pin | |
| contact surface | tin-plated | |
| Rated voltage | 630 V | |
| Rated current | 16 A | |
| Orientation | angled | |
| Pin number | 7 pole | |
| Grid | 7.5 mm | |
| Type of locking | No |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
