231-538/001-000 | WAGO
Pin header, 8 pole, pitch 5.08 mm, angled, orange, 231-538/001-000
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
2.5228 € *
Available: 54 pcs.
Total Price:
2.52 € *
Price list
Quantity
Price per unit*
1 pcs.
2.5228 €
10 pcs.
2.3324 €
50 pcs.
2.1182 €
100 pcs.
1.9159 €
*incl. VAT plus shipping costs
Subject to prior sale
Pin header, 231-538/001-000, WAGO
THT male header, 1.0 x 1.0 mm solder pin, angled, Pin spacing 5.08 mm, 8-pole, orange.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | pin header | |
| Contact type | pin | |
| Pin number | 8 pole | |
| Grid | 5.08 mm | |
| Connection | solder pin | |
| Orientation | angled | |
| Type of locking | No | |
| contact surface | tin-plated | |
| Connection plating | tin-plated | |
| Rated voltage | 320 V | |
| Rated current | 12 A | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Colour | orange |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
