ZSC00AD2201HARL | Vishay
Electrolytic capacitor, 22 µF, 50 V (DC), ±20 %, SMD, Ø 6.3 mm, ZSC00AD2201HARL
Unit Price (€ / pc.)
0.0893 € *
Standard delivery time from the manufacturer is: 20 Weeks
SMD aluminum electrolytic capacitor, type Vishay ZSC.
With base plate, vertical construction, low impedance, high ripple current
Rated voltage 50 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Design | SMD | |
| max. operating temperature | 105 °C | |
| Version | polar | |
| Capacity | 22 µF | |
| diameter | 6.3 mm | |
| Ripple current | 165 mA | |
| min. operating temperature | -55 °C | |
| Tolerance | ±20 % | |
| Rated voltage (DC) | 50 V | |
| Length | 5.7 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
