TSP-BCM12 | TRACO POWER
Power supply, 12 to 14 VDC, 12 A, 144 W, TSP-BCM12
Unit Price (€ / pc.)
180.1898 € *
Available: 0 pcs.
Leadtime: 22 Weeks **
Total Price:
180.19 € *
Price list
Quantity
Price per unit*
1 pcs.
180.1898 €
10 pcs.
162.1494 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power supply, TSP BCM12, Traco
This module provides a professional battery management system for charging and monitoring an external lead-acid battery. The connected battery is charged by the power supply and kept in the state of charge. In the event of a power failure, the battery provides the output power until the battery is discharged. To avoid overcharging the battery, an external temperature sensor automatically adjusts the battery voltage to the required end-of-charge voltage. This can extend the service life of the battery.
Features
- Battery protection for overvoltage, deep discharge, short circuit and polarity reversal
- Alarm outputs for input, output and battery status
- Remote On/Off for battery and power supply
- Controlled charging end voltage by temperature sensor
- International security
Technical specifications
| Degree of protection (IP) | IP20 | |
| Depth | 110 mm | |
| Output voltage DC | 12 to 14 VDC | |
| Output current | 12 A | |
| Width | 35 mm | |
| Height | 110 mm | |
| Power | 144 W | |
| Number of outputs | 1 | |
| Input voltage AC | 12-14 VDC |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
