TBLC 75-112 | TRACO POWER
Power supply, 12 to 16 VDC, 6 A, 72 W, TBLC 75-112
Unit Price (€ / pc.)
88.6074 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Total Price:
88.61 € *
Price list
Quantity
Price per unit*
1 pcs.
88.6074 €
10 pcs.
79.7419 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power supply, TBLC 75-112, Traco
This power supply is designed for industrial and residential applications. It is intended for connection as a Class II device, so the protective earth connection is not required. The device can be mounted in shallow racks due to its small dimensions in depth.
Features
- High power density in flat housing, module depth < 55 mm
- Suitable for installation in domestic installation panels
- Sehr hoher Wirkungsgrad und geringe Standby-Leistung
- Low output ripple and spikes
- For distributed power
- Operating temperature range: -25°C to +70°C
Applications
- Household applications
- Industrial application
Technical specifications
| Number of outputs | 1 | |
| Output voltage DC | 12 to 16 VDC | |
| Output current | 6 A | |
| Width | 72 mm | |
| Input voltage AC | 85-264 VAC | |
| Height | 59.5 mm | |
| Power | 72 W | |
| Degree of protection (IP) | IP20 | |
| Depth | 89.5 mm | |
| efficiency | 89 % |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
