THL 10-4813WI | TRACO POWER
DC converter, 18-75 VDC, 9.9 W, 1 output, 15 VDC, 87 % efficiency, THL 10-4813WI
Unit Price (€ / pc.)
35.8428 € *
Standard delivery time from the manufacturer is: 14 Weeks
Total Price:
35.84 € *
Price list
Quantity
Price per unit*
1 pcs.
35.8428 €
10 pcs.
32.2609 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco THL 10-4813WI
The THL 10WI is a series of general purpose 10 Watt dc/dc-converters packed in the compact 1” x 1” case and is a pin to pin replacement for the popular 1” x 2” size products. The industrial standard pinout, the ultra wide 4:1 input voltage range and the input filter that meets EN 55022 Class A without external components make these converters easy to design in and suitable for to cost optimize many existing and new applications. The models have a remote On/Off control, short circuit and overvoltage protection and are applicable in temperature ranges of up to +75°C or +85°C with optional mounted heat sink. Typical applications are instrumentation, distributed power architectures in communication and industrial electronics
Technical specifications
| Number of outputs | 1 | |
| Output current | 660 mA | |
| Output voltage DC | 15 VDC | |
| Input voltage AC | 18-75 VDC | |
| Power | 9.9 W | |
| efficiency | 87 % | |
| Design | DIP6 | |
| Isolation voltage | 1.5 kV | |
| Length | 25.4 mm | |
| Width | 25.4 mm | |
| Height | 10.2 mm |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
