TEP 200-7210WIRCMF | TRACO POWER
DC/DC converter, 43-160 VDC, 188 W, 1 output, 3.3 VDC, 87 % efficiency, TEP 200-7210WIRCMF
Unit Price (€ / pc.)
522.2315 € *
Available: 0 pcs.
Leadtime: 21 Weeks **
Total Price:
522.23 € *
Price list
Quantity
Price per unit*
1 pcs.
522.2315 €
10 pcs.
470.0024 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TEP 200-7210WIRCMF
The TEP 200WIR Series is a family of isolated high performance dc-dc converter modules with ultra-wide 4:1 input voltage ranges. They come in chassis mount version with screw terminal block and with integrated EMI input filter to meet EN 55032 class A. A very high efficiency allows full power operation at 25°C with only 100 LFM air flow couling and operation at 60°C with only 40% power derating. The very wide input voltage range and reverse input voltage protection make these converters interesting solution for battery operated systems. Typical applications are in telecom/datacom, industry control and railway systems for on board power distribution.
Technical specifications
| Number of outputs | 1 | |
| Output voltage DC | 3.3 VDC | |
| Output current | 57 A | |
| Design | 1/2 Brick | |
| Width | 61 mm | |
| Input voltage AC | 43-160 VDC | |
| Height | 38.9 mm | |
| Isolation voltage | 2.25 kV | |
| Length | 85.1 mm | |
| Power | 188 W | |
| efficiency | 87 % |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
