TEN 8-7213WI | TRACO POWER
DC converter, 43-160 VDC, 8 W, 1 output, 15 VDC, 86 % efficiency, TEN 8-7213WI
Unit Price (€ / pc.)
46.1006 € *
Available in 7 Days: 380 pcs. - if ordered today
Total Price:
46.10 € *
Price list
Quantity
Price per unit*
1 pcs.
46.1006 €
10 pcs.
41.4953 €
*incl. VAT plus shipping costs
Subject to prior sale
DC/DC converters, Traco TEN 8-7213WI
The TEN 8WI series is a family of high performance 8 Watt dc/dc converter modules featuring ultra wide 4:1 input voltage ranges in a DIP-24 package with industry- standard footprint. Input voltages up to 160 VDC, excellent EMC characteristics and EN 50155 approval make this product the best choice for many demanding applications in railroad and transportation systems. Further standard features include remote On/Off, over voltage protection, under voltage lockout and short circuit protection. Typical applications for these converters are also in wireless networks, telecom/datacom, industry control systems and measurement equipment.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of outputs | 1 | |
| Output current | 533 mA | |
| Output voltage DC | 15 VDC | |
| Input voltage AC | 43-160 VDC | |
| Power | 8 W | |
| efficiency | 86 % | |
| Design | DIP24 | |
| Isolation voltage | 1.5 kV | |
| Length | 32 mm | |
| Width | 20.3 mm | |
| Height | 10.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85044095 |
| Country of origin | TW |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
