TDR 3-2412WI | TRACO POWER

DC converter, 9-36 VDC, 3 W, 1 output, 12 VDC, 82 % efficiency, TDR 3-2412WI

Order No.: 26K3365
MPN:
TDR 3-2412WI
Series: TDR 3WI
TDR 3-2412WI TRACO POWER DC/DC Converters
Image may differ
Unit Price (€ / pc.)
37.2232 € *
Standard delivery time from the manufacturer is: 20 Weeks
Total Price:
372.23 € *
*incl. VAT plus shipping costs
Subject to prior sale
10 pcs.
37.2232 €

DC/DC Converter, TDR 3-2412WI, TRACO POWER

The TDR 3-2412WI is a compact 3W DC/DC converter with 4:1 input voltage range and tightly regulated output voltage even under no load conditions. The product is available in THD-package. A TDR 3-2412WI converter is the ideal solution for space critical high end applications.

Features

  • Low ripple and noise
  • Fully regulated outputs
  • Continuous short-circuit protection
  • Remote On/Off control

Applications

  • Communication equipment
  • Instrumentation
  • Industrial electronics
Technical specifications
Filter Property Value
Number of outputs 1
Output current 250 mA
Output voltage DC 12 VDC
Input voltage AC 9-36 VDC
Power 3 W
efficiency 82 %
Design DIP14
Isolation voltage 1.6 kV
Length 18.9 mm
Width 12.8 mm
Height 8.7 mm
Logistics
Property Value
Country of origin TW
Customs tariff number 85044095
Compliance
Property Value
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
