SN74LS14N | Texas Instruments
Hex schmitt trigger inverter, PDIP-14, Texas Instruments SN74LS14N
Unit Price (€ / pc.)
0.8211 € *
Available: 415 pcs.
Total Price:
0.82 € *
Price list
Quantity
Price per unit*
1 pcs.
0.8211 €
25 pcs.
0.6783 €
250 pcs.
0.5593 €
1000 pcs.
0.4998 €
2000 pcs.
0.4522 €
*incl. VAT plus shipping costs
Subject to prior sale
Inverting buffer and driver, SN74LS14N, Texas Instruments
The SN74LS14N is a hex schmitt trigger inverter and has different input threshold levels for positive-going (VT+) and negative-going (VT–) signals. This device temperature compensated and can be triggered from the slowest of input ramps and still give clean, jitter-free output signals.
Features
- Operation from very slow edges
- Improved line-receiving characteristics
- High noise immunity
Applications
- Residential ductless air conditioning outdoor units
- Power meter and power analyzers
- Digital input modules for factory automation
- Industrial stepper motors
- HVAC gateways
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 70 °C | |
| min. operating temperature | 0 °C | |
| Assembly | THT | |
| Output current | 8 mA | |
| Input voltage | 5.25 V | |
| Product type | hex schmitt trigger inverter | |
| Enclosure | PDIP-14 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85423390 |
| MSL | MSL 1 |
| Original Packaging | Bar with 25 pieces |
| Country of origin | MY |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
