100023247 | Telegärtner
Socket header, 8 pole, pitch 3 mm, straight, black, 100023247
Unit Price (€ / pc.)
7.2233 € *
Available: 28 pcs.
Total Price:
7.22 € *
Price list
Quantity
Price per unit*
1 pcs.
7.2233 €
10 pcs.
6.6997 €
25 pcs.
6.2594 €
50 pcs.
5.6882 €
*incl. VAT plus shipping costs
Subject to prior sale
Female connectors to DIN 41622, type Telegärtner J0004.
With silver-plated contacts. Insulating parts made of glass fiber-reinforced polycarbonate, black; Connections: tinned solder terminals. Contact arrangement: asymmetric. Test class to DIN IEC 60068-1: 40/085/21. Breakdown voltage: 1500 VRMS/50 Hz. Operating current (20 °C): 8.0 A. Operating voltage: 380 VAC/450 VDC. Useful life: 500 Insertion/removal cycles. Dimension: a 47, b 38, c 15, d 14, e 32 mm.
Female connectors.
Type: J00040A0911, 8 - pole, size 1
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 8 A | |
| contact surface | silver-plated | |
| Colour | black | |
| Additional parts | equipped | |
| Contact type | socket | |
| Connection plating | tin-plated | |
| Grid | 3 mm | |
| Orientation | straight | |
| Rated voltage | 380 V | |
| Connection | PCB connection | |
| Pin number | 8 pole | |
| Version | socket header | |
| Type of locking | No | |
| Number of rows | 2 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369010 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
