100011205 | Telegärtner
Patch cable kit, MT/MPO to LC, 0.5 m, OM4, multimode 50/125 µm, 100011205
Order No.: 80F2735
EAN: 4018359470531
MPN:
100011205
L00839A0024
Unit Price (€ / pc.)
283.7317 € *
Standard delivery time from the manufacturer is: On Request
L00839A0024 from Telegärtner at Bürklin Elektronik
Find detailed information about the product on our site L00839A0024 from Telegärtner. The manufacturer's description for this product is: MPO/MTP toteilader OM4, 12x LC, 0,5 mMore information about L00839A0024
- Fiber type: G50/125 OM4
- Connector design: 1. site MPO PC, 2. site LC PC
- Length: 0.5 m
- Housing color: MPO PC: black, LC PC: black
Technical attributes
- Number of fibers: 12
- APC execution: false
- Fiber type: Multimode 50/125
- Flame retardant: according to EN 50265-2-1
- Halogen-free according to EN 50267-2-3: true
- Cable type: Simplex
- Category: OM4
- Cable bend relief: pinned
- Length: 0.5
- Jacket color: other
- Connector type connection 1: MT/MPO
- Connector type connection 2: LC
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Chamfer type | multimode 50/125 µm | |
| Connection (1) | MT/MPO | |
| Cable length | 0.5 m | |
| Material | polymer | |
| Version | patch cable kit | |
| Category | OM4 | |
| Connection (2) | LC |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85447000 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
