100024921 | Telegärtner
SMB socket 50 Ω, KX-21A, RG-178B/U, RG-196A/U, crimp connection, straight, 100024921
Order No.: 77F894
EAN: 4018359126339
MPN:
100024921
J01191A0001
Unit Price (€ / pc.)
18.6354 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
93.18 € *
Price list
Quantity
Price per unit*
5 pcs.
18.6354 €
10 pcs.
17.1360 €
50 pcs.
15.7794 €
100 pcs.
13.3875 €
*incl. VAT plus shipping costs
Subject to prior sale
Coaxial connector, J01191A0001, Telegärtner
SSMB Straight Jack Crimp G3 (RG-178B/U)
This product utilizes a snap coupling and is suitable for applications up to a frequency of 3 GHz. Connector designs are available for flexible cables like RG-316 and RG-178. Because of the small size, this connector has applications in small instruments and communication equipment.
Technical Data
- Design: Jack
- Connector type: SMB
- Cable group: RG 178B/U
- Angled connector: false
- Insulated mounting: false
- Impedance: 50 Ω
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Impedance | 50 Ω | |
| Connector | SMB | |
| Cable Group | KX-21A, RG-178B/U, RG-196A/U | |
| Design | straight | |
| Contact material | brass | |
| Contact connection | crimp connection | |
| Version | socket |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366910 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
