2-2176324-2 | TE Connectivity
Resistor, metal film, SMD, 5.6 MΩ, 3 W, ±5 %, 2-2176324-2
Unit Price (€ / pc.)
0.7021 € *
Available: 0 pcs.
Available in 5 Days: 1,000 pcs.
Leadtime: 1 Week **
Total Price:
0.70 € *
Price list
Quantity
Price per unit*
500 pcs.
0.7021 €
1000 pcs.
0.4998 €
*incl. VAT plus shipping costs
**Subject to prior sale
Resistor, 2-2176324-2, TE Connectivity
The 2-2176324-2 provides high stable performance against environmental conditions and overload. This product has flameproof UL94V0 molded package, and is resistant to sulfuration, heat and humidity.
Features
- High surge withstanding and pulse withstanding performance
- Excellent mechanical strength and electrical stability
Technical specifications
| ohmic resistance | 5.6 MΩ | |
| Design | SMD | |
| Height | 6.8 mm | |
| Length | 13.5 mm | |
| Power | 3 W | |
| max. operating temperature | 200 °C | |
| min. operating temperature | -65 °C | |
| Tolerance | ±5 % | |
| Technology | metal film | |
| Temperature coefficient | ±200 ppm/°K |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85332100 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
