1SNK705011R0000 | TE Connectivity

Terminal block, push-in spring connection, 2.5 mm², 3 pole, 24 A, 8 kV, gray, 1SNK705011R0000

Order No.: 71P4354
EAN: 4099891649463
Series: SNK
TE Connectivity
default L
front L
side L
back L
top L
Image may differ
Unit Price (€ / pc.)
0.9877 € *
Available: 0 pcs.
Available in 5 Days: 1,750 pcs.
Leadtime: 1 Week **
Total Price:
0.99 € *
Price list
Price per unit*
100 pcs.
0.9877 €
500 pcs.
0.8687 €
*incl. VAT plus shipping costs
**Subject to prior sale

PCB Terminal, 1SNK705011R0000, TE Connectivity

The 1SNK705011R0000 is a screw clamp terminal block that offers rationalized functions and accessories while serving a large scope of applications. Asymmetrical design avoid mounting and wiring errors. This product has Intuitive codification, simplified catalogs and large technical data base.


  • Easy to install
  • Optimized logistics
Technical specifications
Connection push-in spring connection
Version PI spring terminal block
AWG cross-section AWG 12
Rated Voltage 1000 V
Rated surge voltage 8 kV
Width 5.2 mm
Colour gray
Height 64.7 mm
Length 40.2 mm
Cable cross-section 2.5 mm²
Rated current 24 A
Pin number 3 pole
Degree of soiling 3
Country of origin FR
Customs tariff number 85369010
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
