Hybrid header: no, Connector system: wire-to-board, Sealable: yes, Connector & contact terminates to: printed circuit board, Number of signal positions: 26, Number of positions: 26, PCB mount orientation: vertical, Number of rows: 4, Operating voltage: 250 VAC, Primary product color: black, Mating pin diameter: 1 mm, Contact mating area plating material: gold (Au), Termination method to printed circuit board: through hole-solder, PCB mount retention: without, Centerline (pitch): 3 mm, Product length: 36.5 mm, Operating temperature (max): 125 °C, Operating temperature range: -40-125 °C, -40-125 °C, Shielded: no, Circuit application: signal, Packaging quantity: 17
Connection | solder connection | |
Number of rows | 4 | |
Version | straight | |
Colour | black | |
Contact type | plug | |
contact surface | gold-plated | |
Rated voltage | 250 V | |
Pin number | 26 pole | |
Grid | 3 mm | |
Type of locking | Yes |
Country of origin | IN |
Customs tariff number | 85366990 |
RoHS conform | Yes |
Date of RoHS guidelines | 3/31/15 |
SVHC free | Yes |
