66.9406-10022 | Stäubli Electrical Connectors

Measuring lead with (4 mm plug, spring-loaded, straight) to (4 mm plug, spring-loaded, straight), 1 m, red, silicone, 1.0 mm², CAT II, 66.9406-10022

Order No.: 86F9187
EAN: 842640117355
MPN:
66.9406-10022
XZG410/SIL 1,00M ROT
66.9406-10022 Stäubli Electrical Connectors Test Leads Image 1
66.9406-10022 Stäubli Electrical Connectors Test Leads Image 2
66.9406-10022 Stäubli Electrical Connectors Test Leads Image 3
Image may differ
Unit Price (€ / pc.)
12.6497 € *
Next delivery: 24 pcs. on 2025-06-02
Total Price:
12.65 € *
Price list
Quantity
Price per unit*
1 pcs.
12.6497 €
25 pcs.
11.7096 €
50 pcs.
10.7576 €
100 pcs.
10.1269 €
500 pcs.
9.4962 €
*incl. VAT plus shipping costs
Subject to prior sale

Measuring lead, 66.9406-10022, Stäubli Electrical Connectors

Highly flexible, with silicone insulation, especially for connecting electrical devices that are not (yet) equipped with safety sockets. are not (yet) equipped with safety sockets. On both sides with stackable Ø 4 mm laminated plug with protective collar and sliding sleeve for protection against accidental contact.

Technical specifications
Connection (1) 4 mm plug, spring-loaded, straight
Connection (2) 4 mm plug, spring-loaded, straight
Cable length 1 m
Cable cross-section 1.0 mm²
Colour red
Material silicone
contact surface nickel-plated
Rated category CAT II
Rated Voltage 600 V
Rated current 19 A
Touch safe Yes
Stackable Yes
Logistics
Customs tariff number 85444290
Country of origin DE
Original Packaging Bag with 25 pieces
Compliance
SVHC free No
Substance description Lead
Date of RoHS guidelines 3/31/15
RoHS conform Yes
