65.3300-25 | Stäubli Electrical Connectors

1.5 mm panel socket, round plug connection, mounting Ø 10.5 mm, green, 65.3300-25

Order No.: 22F7264
EAN: 4099891759391
MPN:
65.3300-25
MLB 1,5-R GRÜN
Series: Medicalline
65.3300-25 Stäubli Electrical Connectors Laboratory Connectors Image 1
65.3300-25 Stäubli Electrical Connectors Laboratory Connectors Image 2
Image may differ
Unit Price (€ / pc.)
2.3324 € *
Available: 14 pcs.
Leadtime: On Request **
Total Price:
2.33 € *
Price list
Quantity
Price per unit*
1 pcs.
2.3324 €
10 pcs.
2.1420 €
50 pcs.
2.0111 €
100 pcs.
1.8802 €
500 pcs.
1.7493 €
*incl. VAT plus shipping costs
**Subject to prior sale

Touch-proof mounting socket, 65.3300-25, Stäubli Electrical Connectors

The 65.3300-25 is an insulated mounting socket according to DIN 42802, with rigid, gold-plated Ø 1.5 mm pin, suitable for holding spring-loaded Ø 1.5 mm sockets. Assembly by mounting or installation in holes in plates or housings made of plastic, metal etc.

Technical specifications
Colour green
Installation diameter 10.5 mm
contact surface gold-plated
diameter 1.5 mm
Length 29 mm
Stackable No
Touch safe Yes
Version panel socket
Connection round plug connection
Logistics
Country of origin DE
Customs tariff number 85369010
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
