64.1020-23 | Stäubli Electrical Connectors
4 mm plug, solder connection, 2.5 mm², blue, 64.1020-23
Unit Price (€ / pc.)
2.4990 € *
Available: 49 pcs.
Leadtime: 2 Weeks **
Total Price:
2.50 € *
Price list
Quantity
Price per unit*
1 pcs.
2.4990 €
25 pcs.
2.1301 €
100 pcs.
1.9635 €
500 pcs.
1.8683 €
1000 pcs.
1.7017 €
*incl. VAT plus shipping costs
**Subject to prior sale
4 mm Plug, 64.1020-23, Stäubli Electrical Connectors
In-line, Ø 4 mm, with spring-loaded MULTILAM for self-assembly of test leads.
Technical specifications
| Connection | solder connection | |
| Version | plug | |
| Rated Voltage | 30 VAC/60 VDC | |
| Rated current | 32 A | |
| Touch safe | No | |
| diameter | 4 mm | |
| Colour | blue | |
| contact surface | gold-plated | |
| Length | 69 mm | |
| Cable cross-section | 2.5 mm² | |
| max. Cable diameter | 3.9 mm | |
| Stackable | No |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
