8WD5340-0CC | Siemens
Recessed LED flashing light, Ø 70 mm, green, 115 VAC, IP65, 8WD5340-0CC
Order No.: 80P9723
EAN: 4011209359321
MPN:
8WD5340-0CC
8WD53400CC
Unit Price (€ / pc.)
178.6785 € *
Standard delivery time from the manufacturer is: 1 Week
Integrated signal lamp, single flash light, w. built-in electronic flash, green, 115 V AC, Diameter 70 mm Flashlight element SIRIUS 8WD5 including light sources for visual signaling in harsh ambient conditions and in outdoor installations, e.g. for the optical signaling of the operating status in production plants. The integrated signal lamps are extremely resistant to shock and vibrations. Their special shape permits optimum light emission either to the side or upwards. Feet, pipes, adapters, incandescent lamps, LEDs and pipe adapters are available as accessories. SIRIUS 8WD signaling column - Modular and with communication capability.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Farbe der Beleuchtung | green | |
| Height | 66 mm | |
| Colour | green | |
| Degree of protection (IP) | IP65 | |
| Rated current | 22 mA | |
| Version | blinking light | |
| diameter | 70 mm | |
| Width | 75 mm | |
| Voltage | 115 VAC | |
| Length | 31 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85318070 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
