8020.5014 | SCHURTER

Name: Microfuses 6.3 x 32 mm, 2 A, T, 400 V (DC), 500 V (AC), 1.5 kA breaking capacity, 8020.5014
Brand: SCHURTER
SKU: 43G806
Price: 0.38 EUR
Availability: InStock

Microfuses 6.3 x 32 mm, 2 A, T, 400 V (DC), 500 V (AC), 1.5 kA breaking capacity, 8020.5014

Order No.: 43G806

EAN: 4099889089004

MPN:

8020.5014

Series: SHT 6.3x32

Image may differ

Key Specification:

Version microfuses

Design 6.3 x 32 mm

Enclosure ceramic tube

Rated current 2 A

Tripping characteristics T

Show 16 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.3808 € *

Available: 250 pcs.

Leadtime: 17 Weeks **

Total Price:

0.38 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Micro fuse, 8020.5014, SCHURTER

The 8020.5014 is a time-lag cartridge fuse that allows for a temporary current surge without going above the fuse's current rating. Because of this time delay fuses are most commonly used to protect motor circuits.

Features

Material tube ceramic
Material endcaps copper alloy nickel-plated
Time-lag
High breaking capacity

Applications

Single-phase application
DC application
Photovoltaic
Frequency converter
Power electronics

Download

Technical Data Sheet - EN Technical Data Sheet

Declaration of Conformity - EN Declaration of Conformity

Technical Data Sheet - DE Technical Data Sheet

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	CN
Customs tariff number	85361010
Original Packaging	Carton with 10 pieces

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes
