Name: Microfuses 5 x 20 mm, 3.15 A, F, 250 V (AC), 1.5 kA breaking capacity, 0001.1009
Brand: SCHURTER
SKU: 43G112
Price: 0.17 EUR
Availability: InStock

Microfuses 5 x 20 mm, 3.15 A, F, 250 V (AC), 1.5 kA breaking capacity, 0001.1009

Order No.: 43G112

EAN: 4099889087956

MPN:

0001.1009

Series: SP 5x20

Image may differ

Key Specification:

Version microfuses

Design 5 x 20 mm

Enclosure ceramic tube

Rated current 3.15 A

Tripping characteristics F

Show 17 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.1690 € *

Available: 10 pcs.

Leadtime: 17 Weeks **

Total Price:

0.84 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Micro fuse, 0001.1009,SCHURTER

The 0001.1009 is a quick-acting cartridge fuse with that is designed to protect less sensitive components and is also used to protect cabling from melting or catching fire when an overload occurs.
