KMF1.1193.11 | SCHURTER

IEC plug C14/C18, 50 to 60 Hz, 10 A, 250 VAC, 1.6 W, 400 µH, faston plug 4.8 mm, KMF1.1193.11

default S
default L
Total price
(25.28 € * / pcs.)
25.28 €
Available: 10 pcs.
Quantity
Price per unit*
1 pcs.
25.28 €
3 pcs.
24.20 €
5 pcs.
23.21 €
10 pcs.
22.29 €
*incl. VAT plus shipping costs
Show 10 variants
Description

Product by SCHURTER at Bürklin Elektronik

IEC appliance inlet, KMF1.1193.11, SCHURTER

The KMF1.1193.11 is a power entry module with line filter. This product is designed for use in industrial environments, also has approval from independent testing bodies according to national and international standards.

Features

  • Most compact solution on the market
  • Innovative EMC-shielding
  • Easy and flexible snap-in mounting
  • Flexible steel segments for an excellent contact
  • Suitable for use in medical equipment
Technical specifications
ohmic resistance 1000000 Ω
Connection faston plug 4.8 mm
Version IEC plug C14/C18
Rated Voltage 250 VAC
Inductance per line 0.4 mH
integrated switch Yes
Capacity X|Y X2 47 nF
Power 1.6 W
max. frequency 0.00006 MHz
max. operating temperature 85 °C
min. frequency 0.00005 MHz
min. operating temperature -25 °C
With fuse Yes
Rated current 10 A
Show similar products (0)
Logistics
Country of origin CZ
Customs tariff number 85363010
MSL MSL 1
Original Packaging Carton with 20 pieces
Compliance
Guidline date 3/31/15
RoHS confom Yes
SVHC date 1/16/20
SVHC free Yes
Variations
1 item with 10 variations
Item description
Price list
Total
ohmic resistance
Version
Rated Voltage
Capacity X|Y
max. frequency
Connection
min. operating temperature
max. operating temperature
Rated current
min. frequency
Power
IEC plug C14/C18, 50 to 60 Hz, 4 A, 250 VAC, 1.6 W, 1.6 mH, faston plug 4.8 mm, KMF1.1143.11
Order No.:
 59P9598
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1143.11
1 pcs.
25.28 €
3 pcs.
24.20 €
5 pcs.
23.21 €
10 pcs.
22.29 €
25.28 € *
Available: 1 pcs.
Next delivery: 40 pcs. on 2023-03-24
1000000 Ω
IEC plug C14/C18
250 VAC
X2 47 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
4 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 10 A, 250 VAC, 1.6 W, 400 µH, faston plug 4.8 mm, KMF1.1193.11
Order No.:
 59P9602
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1193.11
1 pcs.
25.28 €
3 pcs.
24.20 €
5 pcs.
23.21 €
10 pcs.
22.29 €
25.28 € *
Available: 10 pcs.
1000000 Ω
IEC plug C14/C18
250 VAC
X2 47 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
10 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 6 A, 250 VAC, 1.6 W, 700 µH, faston plug 4.8 mm, KMF1.1163.11
Order No.:
 59P9600
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1163.11
40 pcs.
25.17 €
0.00 € *
Currently not in stock, we will order for you
1000000 Ω
IEC plug C14/C18
250 VAC
X2 47 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
6 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 2 A, 250 VAC, 1.6 W, 4 mH, faston plug 4.8 mm, KMF1.1123.11
Order No.:
 59P9596
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1123.11
1 pcs.
25.28 €
3 pcs.
24.20 €
5 pcs.
23.21 €
10 pcs.
22.29 €
25.28 € *
Available: 40 pcs.
1000000 Ω
IEC plug C14/C18
250 VAC
X2 47 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
2 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 2 A, 250 VAC, 1.6 W, 4 mH, faston plug 4.8 mm, KMF1.1121.11
Order No.:
 59P9595
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1121.11
1 pcs.
22.43 €
4 pcs.
21.47 €
8 pcs.
20.58 €
20 pcs.
19.77 €
0.00 € *
Next delivery: 39 pcs. on 2023-03-31
IEC plug C14/C18
250 VAC
X2 47 nF, Y2 2.2 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
2 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 6 A, 250 VAC, 1.6 W, 700 µH, faston plug 4.8 mm, KMF1.1161.11
Order No.:
 59P9599
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1161.11
1 pcs.
22.43 €
4 pcs.
21.47 €
8 pcs.
20.58 €
20 pcs.
19.77 €
0.00 € *
Next delivery: 20 pcs. on 2023-07-28
IEC plug C14/C18
250 VAC
X2 47 nF, Y2 2.2 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
6 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 10 A, 250 VAC, 1.6 W, 400 µH, faston plug 4.8 mm, KMF1.1191.11
Order No.:
 59P9601
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1191.11
1 pcs.
22.43 €
4 pcs.
21.47 €
8 pcs.
20.58 €
20 pcs.
19.77 €
0.00 € *
Next delivery: 50 pcs. on 2023-03-24
IEC plug C14/C18
250 VAC
X2 47 nF, Y2 2.2 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
10 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 1 A, 250 VAC, 1.6 W, 11 mH, faston plug 4.8 mm, KMF1.1111.11
Order No.:
 59P9593
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1111.11
1 pcs.
22.43 €
4 pcs.
21.47 €
8 pcs.
20.58 €
20 pcs.
19.77 €
0.00 € *
Next delivery: 25 pcs. on 2023-07-07
IEC plug C14/C18
250 VAC
X2 47 nF, Y2 2.2 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
1 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 4 A, 250 VAC, 1.6 W, 1.6 mH, faston plug 4.8 mm, KMF1.1141.11
Order No.:
 59P9597
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1141.11
1 pcs.
22.43 €
4 pcs.
21.47 €
8 pcs.
20.58 €
20 pcs.
19.77 €
0.00 € *
Next delivery: 40 pcs. on 2023-03-24
IEC plug C14/C18
250 VAC
X2 47 nF, Y2 2.2 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
4 A
0.00005 MHz
1.6 W
IEC plug C14/C18, 50 to 60 Hz, 1 A, 250 VAC, 1.6 W, 11 mH, faston plug 4.8 mm, KMF1.1113.11
Order No.:
 59P9594
Manufacturer:
 SCHURTER
Manufacturer SKU
 KMF1.1113.11
40 pcs.
25.17 €
0.00 € *
Currently not in stock, we will order for you
1000000 Ω
IEC plug C14/C18
250 VAC
X2 47 nF
0.00006 MHz
faston plug 4.8 mm
-25 °C
85 °C
1 A
0.00005 MHz
1.6 W
