Storage choke, radial, 0.38 mH, 1.4 A, DSF-28-0004

default S
default L
Total price
(5.22 € * / pcs.)
0.00 €
Currently not in stock, we will order for you
Quantity
Price per unit*
40 pcs.
5.22 €
*incl. VAT plus shipping costs
Description

Product by SCHURTER at Bürklin Elektronik

Storage choke, DSF-28-0004, SCHURTER

The DSF-28-0004 is a storage choke that is used for energy storage in SMPS's. It is made of iron or metal powder cores with one winding.

Features

  • Storage choke
  • Inductor horizontally positioned in housing
  • Reduced magnetic reversal
  • THT-terminals

Applications

  • Storage of energy in switched power supplies
  • Switch-mode
  • Chopper amplifiers
  • DC drives and stepper motor controls
Technical specifications
Version storage choke
Design radial
Width 27.4 mm
DC current 1.4 A
DC resistance 0.16 Ω
Height 16.5 mm
Inductance 0.38 mH
Length 28.3 mm
Tolerance ±15 %
Show similar products (0)
Logistics
Country of origin LK
Customs tariff number 85045000
MSL MSL 1
Original Packaging Carton with 40 pieces
Compliance
Guidline date 3/31/15
RoHS confom Yes
SVHC date 1/16/20
SVHC free Yes
Variations
1 item with 8 variations
Item description
Price list
Total
Design
Version
Width
Length
Tolerance
Height
Inductance
DC current
DC resistance
Storage choke, radial, 0.23 mH, 1.8 A, DSF-28-0005
Order No.:
 59P9057
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0005
40 pcs.
5.22 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
0.23 mH
1.8 A
0.125 Ω
Storage choke, radial, 3.7 mH, 0.45 A, DSF-28-0001
Order No.:
 59P9053
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0001
40 pcs.
5.22 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
3.7 mH
0.45 A
1.9 Ω
Storage choke, radial, 0.38 mH, 1.4 A, DSF-28-0004
Order No.:
 59P9056
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0004
40 pcs.
5.22 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
0.38 mH
1.4 A
0.16 Ω
Storage choke, radial, 0.63 A, DSF-28-0002
Order No.:
 59P9054
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0002
40 pcs.
8.03 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
0.63 A
0.36 Ω
Storage choke, radial, 0.037 mH, 4.5 A, DSF-28-0007
Order No.:
 59P9059
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0007
40 pcs.
5.22 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
0.037 mH
4.5 A
0.02 Ω
Storage choke, radial, 0.75 mH, 1 A, DSF-28-0003
Order No.:
 59P9055
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0003
40 pcs.
5.22 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
0.75 mH
1 A
0.36 Ω
Storage choke, radial, 0.018 mH, 4.5 A, DSF-28-0008
Order No.:
 59P9060
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0008
40 pcs.
5.22 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
0.018 mH
4.5 A
0.01 Ω
Storage choke, radial, 0.075 mH, 3.15 A, DSF-28-0006
Order No.:
 59P9058
Manufacturer:
 SCHURTER
Manufacturer SKU
 DSF-28-0006
40 pcs.
5.22 €
0.00 € *
Currently not in stock, we will order for you
radial
storage choke
27.4 mm
28.3 mm
±15 %
16.5 mm
0.075 mH
3.15 A
0.045 Ω
