0909.0021 | SCHURTER
Panel socket 2-fold F, 3 pole, snap-in, solder connection, black, 0909.0021
Unit Price (€ / pc.)
   7.0805 €  *
   Standard delivery time from the manufacturer is: 14 Weeks
 Total Price:
  7.08 € *
  Price list
 Quantity
 Price per unit*
 1 pcs.
 7.0805 €
 10 pcs.
 6.4379 €
 50 pcs.
 5.9262 €
 100 pcs.
 5.3312 €
  *incl. VAT plus shipping costs
  Subject to prior sale
 Distributor strip, 0909.0021, SCHURTER
Strip block for Snap-in mounting with 2 IEC appliance outlets F.
Features
- Protection class: 1
- Housing material: Thermoplastic, black, UL 94V-0
 Technical specifications

 | Filter | Property | Value |
|---|---|---|
| Rated voltage IEC | 250 V | |
| Pin temperature | 70 °C | |
| Power switch available | No | |
| Colour | black | |
| Assembly | snap-in | |
| Rated voltage UL/CSA | 250 V | |
| Rated current UL/CSA | 15 A | |
| Panel thickness | 1.5 mm | |
| Fuse holder present | No | |
| Design | straight | |
| IEC designation | F | |
| Connection | solder connection | |
| Switch illuminated | No | |
| Product type | panel socket | |
| Pin number | 3 pole | |
| Version | 2-fold | |
| Type of locking | No | |
| Rated current IEC | 10 A | |
| Line filter present | No |
 Download
  Logistics

 | Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| MSL | MSL 1 |
| Country of origin | TW |
 Compliance

 | Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
