HSEB 3125 L NI / GE | SCHÜTZINGER
4 mm socket, flat plug connection, mounting Ø 12.2 mm, CAT IV, yellow, HSEB 3125 L NI / GE
Unit Price (€ / pc.)
4.7481 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
4.75 € *
Price list
Quantity
Price per unit*
1 pcs.
4.7481 €
10 pcs.
4.4982 €
50 pcs.
4.2483 €
100 pcs.
3.9984 €
500 pcs.
3.7604 €
*incl. VAT plus shipping costs
Subject to prior sale
Laboratory connector, HSEB 3125 L NI / GE, SCHÜTZINGE
The HSEB 3125 L NI / GE is a high voltage safety threaded socket for fixture in panels up to 13.5 mm thick and it is fixed by a hexagon nut.
Features
- Plug-in connection
- High rated current
- High rated voltage
- Nickel plated contacts
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated category | CAT IV | |
| Touch safe | Yes | |
| Installation diameter | 12.2 mm | |
| contact surface | nickel-plated | |
| Connection | flat plug connection | |
| Colour | yellow | |
| Rated current | 16 A | |
| Rated Voltage | 6000 V | |
| Length | 48 mm | |
| diameter | 4 mm | |
| Version | socket |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
