SDK 503 / GR | SCHÜTZINGER
Quick pressure clamp, gray, 30 VAC/60 VDC, 16 A, thread, nickel-plated, SDK 503 / GR
Order No.: 30F3581
EAN: 4099889681277
MPN:
SDK 503 / GR
99014900
Unit Price (€ / pc.)
8.2705 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
8.27 € *
Price list
Quantity
Price per unit*
20 pcs.
8.2705 €
60 pcs.
7.5922 €
100 pcs.
7.1638 €
*incl. VAT plus shipping costs
**Subject to prior sale
Quick release terminals with solder terminals for front-panel mounting, type Schützinger SDK 503/.
For fast and safe contacting of stranded wire and solid wire without tools, vibration-proof through integrated gill plate, easy release; Installation: insulated, for metallic front panels (0.8 to 5.0 mm thickness). Connection: solder lug or cable lug. Rated voltage: 33 VAC/70 VDC. Rated current: 16 A. Contact resistance: max. 5.0 mohm. Insulating parts: PA 6.6. Contact parts: nickel-plated. Operating temperatures: –25 to +90 °C.
Technical attributes (type, pushbutton color (type SDK 503/GNGE with yellow housing and green pushbutton)): SDK 503/GR, gray
Technical specifications
| Connection | thread | |
| Rated Voltage | 30 VAC/60 VDC | |
| Rated current | 16 A | |
| Installation diameter | 10 mm | |
| Colour | gray | |
| contact surface | nickel-plated | |
| Length | 52.5 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
