M9F11450 | Schneider Electric

Circuit breaker, 4 pole, C Curve, 50 A, 415 V, DIN rail, M9F11450

Order No.: 03P7883
EAN: 3606480576560
MPN:
M9F11450
Series: Multi 9
M9F11450 Schneider Electric Circuit Protectors
Image may differ
Unit Price (€ / pc.)
258.6941 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
258.69 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
258.6941 €

Circuit breaker, M9F11450, SCHNEIDER

The M9F11450 is a low voltage miniature circuit breaker. It is a 4P circuit breaker with 4 protected poles and 50 A In rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10 kA at 415 V AC. This product protects from short circuit, earth leakage and overload.

Features

  • High breaking capacity
  • High rated impulse withstand voltage
  • High mechanical durability
  • High electrical durability

Applications

  • Semiconductor industry
  • Telecom industries
Technical specifications
Filter Property Value
Product type circuit breaker
Degree of protection (IP) IP20
Pin number 4 pole
Rated voltage (DC) 250 V
Assembly DIN rail
Rated current 50 A
Rated voltage (AC) 440 V
Tripping characteristics C
Rated Voltage 415 V
Logistics
Property Value
Customs tariff number 85362010
Country of origin FR
Compliance
Property Value
Substance description Lead
Sustainable Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
SVHC free No
