9001KR9RH13 | Schneider Electric
Mushroom pushbutton, unlit, latching, 1 Form C (NO/NC), waistband round, red, front ring silver, mounting Ø 30 mm, 9001KR9RH13
Push button, 9001KR9RH13, Schneider Electric
This red push button is part of the range of control and signaling units, Harmony 9001K diameter 30mm metal. It has a chromium-plated metal bezel. It is supplied with a red mushroom diameter 41mm, unmarked It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. It is easily installed into a standard 30mm diameter panel cut-outs. It features 2 maintained positions push pull operator and it is supplied with 1 x C/O contact and screw clamp terminals. It weighs 141g. The 30 mm Harmony range offers a large choice of robust and reliable products to meet a great number of applications in heavy industries such as petrochemy, metallurgy, mining oil and gas wastewater treatment, automobile manufacturing. It is UL listed and CSA certified, CE declaration of conformity and RoHS compliant.
| Filter | Property | Value |
|---|---|---|
| Contact material | silver alloy | |
| can be illuminated | No | |
| Protection class | IP66 | |
| Installation diameter | 30 mm | |
| Front ring colour | silver | |
| Latching switching function | 1 Form C (NO/NC) | |
| Connection | screw connection | |
| Actuator colour | red | |
| Product type | mushroom pushbutton | |
| Collar shape of the front frame | round | |
| Contact function | latching |
| Property | Value |
|---|---|
| Customs tariff number | 85381000 |
| Country of origin | FR |
| Property | Value |
|---|---|
| Sustainable | Yes |
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
