FN284-6-06 | Schaffner
IEC inlet filter C14, 50 to 400 Hz, 6 A, 250 VAC, 450 µH, faston plug 6.3 mm, FN284-6-06
Unit Price (€ / pc.)
33.8317 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
33.83 € *
Price list
Quantity
Price per unit*
1 pcs.
33.8317 €
5 pcs.
31.7968 €
40 pcs.
28.5600 €
80 pcs.
27.7389 €
160 pcs.
26.9178 €
*incl. VAT plus shipping costs
Subject to prior sale
IEC inlet filter with toggle switch and fuse holder, type Schaffner FN 280.
For vertical (top and bottom mounting holes), horizontal (left and right mounting holes), or snap-in mounting, double-pole toggle switch and fuse holder with comfortable access for installation of one or two 5 x 20 mm fuses; Capacitance: Cx 220 nF/Cy 2.2 nF. Leakage current: 373 µA. Operating voltage: 250 VAC, 50/60 Hz. Operating frequency: DC to 400 Hz. Test voltage: 2000 VAC. Connection: 6.3 x 0.8 mm solder/tab terminal combination. Test logo: UL, CSA, ENEC 14.
For horizontal screw mounting, type FN 283/FN 284.
FN 283: 1 fuse. FN 284: 2 fuses.
Technical attributes (type, rated current at +40 °C/+25 °C, rated inductance): FN 284-6-06, 6.0/7.2 A, 0.45 mH
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 6 A | |
| max. operating temperature | 85 °C | |
| Number of phases | 1 | |
| Capacity X|Y | X2 220 nF, Y2 2.2 nF | |
| Version | IEC inlet filter C14 | |
| Rated Voltage | 250 VAC | |
| min. frequency | 50 Hz | |
| max. frequency | 400 Hz | |
| Inductance per line | 450 µH | |
| min. operating temperature | -25 °C | |
| With fuse | Yes | |
| ohmic resistance | 1 MΩ | |
| integrated switch | Yes | |
| Connection | faston plug 6.3 mm |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Carton with 40 pieces |
| Customs tariff number | 85363010 |
| Country of origin | TH |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
