029111000 | Rose
PA/PVC handheld enclosure, (L x W x H) 191 x 280 x 76 mm, yellow/black (RAL 1003), IP65, 029111000
Unit Price (€ / pc.)
185.2473 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
185.25 € *
Price list
Quantity
Price per unit*
1 pcs.
185.2473 €
5 pcs.
175.9891 €
10 pcs.
167.1950 €
50 pcs.
158.8293 €
*incl. VAT plus shipping costs
Subject to prior sale
Portable consoles, type Rose Pilot 50 / 29.11 10 00
For measuring and control/automation technology, variable length through profile technology.
Material: polyamide 6/PVC
Degree of protection: IP 65
Impact resistance: min. 5.0 Joules (DIN 50014)
Combustibility of end caps: HB/UL 94
Color of end caps: rapeseed yellow
PVC profiles: black
Thermal resistance: - 20 to +70 °C
Outer dimensions (W x L x H)): 191 x 280 x 76 mm.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| RAL number | 1003 | |
| Length | 191 mm | |
| Colour | yellow/black | |
| Degree of protection (IP) | IP65 | |
| Material | PA/PVC | |
| Width | 280 mm | |
| Height | 76 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369095 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
