4955073001 | Raychem
Insulated strand/wire, 4955073001
NCNR (non cancelable / non returnable)
Unit Price (€ / mtr.)
3.7485 € *
Standard delivery time from the manufacturer is: 8 Weeks
Low-fire-hazard wire, 4955073001, Raychem
The 4955073001 has a dual wall construction of radiation cross-linked modified polyester. It combines excellent mechanical performance and chemical resistance with a range of enhanced fire hazard properties. This product is designed to meet the stringent low fire hazard performance now being specified by the UK Naval Defense Standard Authority for ship wiring and cabling.
Features
- Low flammability
- Low smoke generation
- Low toxicity index
- Low generation of corrosive gases
- Small size, lightweight
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 22 | |
| Colour | red/blue | |
| Core insulation material | polymer | |
| Outer diameter | 2.4 mm | |
| Cable material | copper, tin-plated | |
| Temperature range (active) | -55 to 120 °C | |
| Rated voltage | 600 V | |
| Test voltage | 2.5 kV |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Country of origin | GB |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
