CB00064001 | Raychem
Heatshrink tubing, 3:1, (4.5/1.5 mm), PE, crosslinked, transparent, CB00064001
Order No.: 35P3289
EAN: 4099891275082
MPN:
CB00064001
RNF-3000-4.5/1.5-X-SP
Unit Price (€ / mtr.)
1.4875 € *
Available: 0 mtr.
Leadtime: 12 Weeks **
Heat shrink tubing, RW-175-E-3/64-X-SP, Raychem
RW-175-E-3/64-X-SP is a highly flame-resistant, high-temperature, chemical-resistant. This product provides tough, semirigid, very-thin-wall insulation and strain relief of multipin connectors, solder joints and other delicate electrical connections and terminations. It is well-suited for applications that require dense packing of components or visual inspection of covered components.
Features
- 2:1 Shrink ratio
- Tough, semirigid, very-thin-wall insulation
- High flame-resistance
- Protection from most industrial solvents, fuels, and chemicals
- Meets NASA outgassing requirements
Technical specifications
| Colour | transparent | |
| Shrinking temperature | 80 °C | |
| contains glue inside | No | |
| Inner diameter before shrinkage | 4.5 mm | |
| Wall thickness | 0.55 mm | |
| Inner diameter after shrinkage | 1.5 mm | |
| min. operating temperature | -55 °C | |
| Material | PE, crosslinked | |
| max. operating temperature | 135 °C | |
| Shrinking rate | 3:1 |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 39173200 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
