3580590013 | Raychem
Heatshrink tubing, 3:1, (3/1 mm), PE, white, 3580590013
Order No.: 35P2807
EAN: 4099891271817
MPN:
3580590013
TRSA-1019/C/1/8
Unit Price (€ / pc.)
0.0988 € *
Available in 5 Days: 8,000 pcs. - if ordered today
Total Price:
9.88 € *
Price list
Quantity
Price per unit*
100 pcs.
0.0988 €
250 pcs.
0.0916 €
500 pcs.
0.0845 €
1000 pcs.
0.0774 €
*incl. VAT plus shipping costs
Subject to prior sale
Heat shrink tubing, DCPT-10/5-45-SP, Raychem
DCPT-10/5-45-SP is a flexible, flame-retardant, dual-color, polyolefin tubing. Also used to identify “ground” on wires and in cables, and to jacket and insulate light-duty harnesses.
Features
- 2:1 and 3:1 Shrink ratio
- Flame-retardance
- Flexibility: able to conform to irregular shapes
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inner diameter after shrinkage | 1 mm | |
| Material | PE | |
| Wall thickness | 0.1 mm | |
| min. operating temperature | -55 °C | |
| Shrinking rate | 3:1 | |
| Shrinking temperature | 80 °C | |
| contains glue inside | No | |
| Colour | white | |
| Inner diameter before shrinkage | 3 mm | |
| max. operating temperature | 135 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | TW |
| Customs tariff number | 39173200 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
