2602674003 | Raychem
Heatshrink tubing, 3:1, (1/0.5 mm), PE, crosslinked, brown, 2602674003
Unit Price (€ / mtr.)
0.8925 € *
Standard delivery time from the manufacturer is: 56 Weeks
Heat shrink tubing, CGPT-51/26-0-SP, Raychem
CGPT-51/26-0-SP is a tough, flexible, general purpose polyolefin tubing with good resistance to common fluids and solvents and a high dielectric strength. Its unique blend of chemical, electrical, and physical properties makes it suitable for a wide range of applications, including electrical insulation, strain relief, cable bundling, colorcoding and identification of wires, cables, pipes, and electrical and electronic components, and mechanical protection.
Features
- 2:1 and 3:1 Shrink ratio
- Very good chemical and solvent resistance
- Flexible
- Excellent physical and electrical performance
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inner diameter before shrinkage | 1 mm | |
| Wall thickness | 0.45 mm | |
| Material | PE, crosslinked | |
| Shrinking rate | 3:1 | |
| Shrinking temperature | 80 °C | |
| max. operating temperature | 135 °C | |
| contains glue inside | No | |
| min. operating temperature | -55 °C | |
| Colour | brown | |
| Inner diameter after shrinkage | 0.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 39269097 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
