1929494001 | Raychem
Heatshrink tubing, 3:1, (18/6 mm), PE, crosslinked, red, 1929494001
Unit Price (€ / mtr.)
3.1654 € *
Standard delivery time from the manufacturer is: 3 Weeks
Heat shrink tubing, CGAT-12/4-0-STK, Raychem
CGAT-12/4-0-STK is a flexible polyolefin heat-shrinkable tubing with an inner meltable adhesive lining designed for the commercial marketplace. It is suitable for the environmental protection of electrical components and the sealing of conductors.
Features
- 3:1 Shrink ratio
- High-strength bonding
- Moisture-proof
- Environmental sealing
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Shrinking rate | 3:1 | |
| contains glue inside | No | |
| min. operating temperature | -55 °C | |
| max. operating temperature | 135 °C | |
| Inner diameter after shrinkage | 6 mm | |
| Wall thickness | 0.85 mm | |
| Inner diameter before shrinkage | 18 mm | |
| Shrinking temperature | 80 °C | |
| Colour | red | |
| Material | PE, crosslinked |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 150 meters |
| Customs tariff number | 39269097 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
