3-1393250-0 | Potter & Brumfield
Circuit breaker, thermal, 1 pole, 15 A, 32 V (DC), 250 V (AC), faston plug 6.3 x 0.8 mm, snap-in, 3-1393250-0
Unit Price (€ / pc.)
4.760 € *
Available in 5 Days: 4,971 pcs. - if ordered today
Total Price:
476.00 € *
Price list
Quantity
Price per unit*
100 pcs.
4.760 €
200 pcs.
4.522 €
*incl. VAT plus shipping costs
Subject to prior sale
Device circuit breaker, 3-1393250-0, POTTER & B
The 2-1393250-0 is a safety device that breaks an electrical circuit if the temperature gets too high. This device is used to prevent fires, damage due to voltage fluctuations, and other dangerous electrical situations.
Features
- Push to reset
- Replaces slow blow glass cartridge fuse
- Labor-saving snap-in mounting
- Button extends for visual trip indication
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | faston plug 6.3 x 0.8 mm | |
| Rated voltage (DC) | 32 V | |
| Rated voltage (AC) | 250 V | |
| Type of mounting | snap-in | |
| Product type | circuit breaker | |
| Pin number | 1 pole | |
| Version | thermal | |
| Actuator | push button | |
| Rated current | 15 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85362010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
