PT 15 NH 5K0 | Piher

Name: Layered trimmer potentiometer, 5 kΩ, 0.25 W, THT, lateral, PT 15 NH 5K0
Brand: Piher
SKU: 66E500
Price: 0.70 EUR
Availability: InStock

Layered trimmer potentiometer, 5 kΩ, 0.25 W, THT, lateral, PT 15 NH 5K0

Order No.: 66E500

EAN: 4099879889850

MPN:

PT 15 NH 5K0

PT15NH05-502A2020--S

Series: PT15

Image may differ

Key Specification:

Version layered trimmer potentiometer

ohmic resistance 5 kΩ

Tolerance ±30 %

Power 0.25 W

Assembly THT

Ordering Information:

Supplied without quick-release shaft and knurled knobs, please order these separately

Show 12 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.7021 € *

Available: 18 pcs.

Available in 4 Days: 3,757 pcs.

Leadtime: 1 Week **

Total Price:

0.70 € *

Price list

Quantity

Price per unit*

1 pcs.

0.7021 €

25 pcs.

0.5593 €

100 pcs.

0.4760 €

250 pcs.

0.4165 €

1000 pcs.

0.3689 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Trimmer potentiometer, PT 15 NH 5K0,Piher

Potentiometer features a 15 mm resistive element made of carbon. Housed in a dust-proof enclosure and has a polyester substrate.

Download

Technical Data Sheet - EN Technical Data Sheet

Declaration of Conformity - EN Declaration of Conformity

Declaration of Conformity - DE Declaration of Conformity

Logistics

Country of origin	ES
Customs tariff number	85334010

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes
