3070011 | Phoenix Contact

Protective conductor terminal, screw connection, 0.14-6.0 mm², 2 pole, 20 A, 8 kV, gray, 3070011

Order No.: 60P5751
EAN: 4046356480239
MPN:
3070011
UT 4-PE/MT
Series: UT
3070011 Phoenix Contact Series Terminals
Image may differ
Unit Price (€ / pc.)
7.0924 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
7.09 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
7.0924 €

Ground modular terminal block, 3070011, Phoenix Contact

Ground modular terminal block, rated voltage: 500 V, nominal current: 20 A, connection method: Screw connection, Rated cross section: 2.5 mm², cross section: 0.14 mm²  - 6 mm², mounting: NS 35/7,5, NS 35/15, color: gray.

Technical specifications
Version protective conductor terminal
Number of terminals 2
Pin number 2 pole
Cable cross-section 0.14-6.0 mm²
AWG cross-section AWG 26 to 10
Rated surge voltage 8 kV
Rated current 20 A
Rated Voltage 500 V
Degree of soiling 3
Length 70.8 mm
Width 6.2 mm
Height 49.1 mm
Connection screw connection
Colour gray
Logistics
Customs tariff number 85369010
Country of origin PL
Compliance
RoHS conform Yes
Substance description Lead
Date of RoHS guidelines 3/31/15
SVHC free No
