1619629 | Phoenix Contact

Jack, M23, 17 pole, crimp connection, screw locking, straight, 1619629

Order No.: 62P0388
EAN: 4046356822497
MPN:
1619629
CA-17F1N8A85DU
Series: CA
1619629 Phoenix Contact Sensor-Actuator Connectors
Image may differ
Unit Price (€ / pc.)
32.6774 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
32.68 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
32.6774 €

Sensor-actuator connector, 1619629, Phoenix Contact

Cable connector, CA, straight, Screw locking, M23, No. of pole: 17, Direction of rotation: Standard, type of contact: Socket, Crimp connection, cable diameter range: 3 mm - 14.5 mm.

Features

  • Shielded
  • Connector for flexible on-site assembly
  • Consistent EMC protection for reliable transmission of signals
  • Crimping connection: vibration- and temperature-resistant assembly
  • Circular connector
Technical specifications
Filter Property Value
Type of locking screw locking
Contact connection crimp connection
Orientation straight
Pin number 17 pole
Assembly cable assembly
Thread size M23
Product type jack
Degree of protection (IP) IP67
Coding N
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
Substance description Lead
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
