1619597 | Phoenix Contact
Socket, M23, 9 pole, solder connection, SPEEDCON locking, straight, 1619597
Order No.: 62P0072
MPN:
1619597
CA-09S1N1280DNS
EAN: 4046356822770
Images may differ
Unit Price (€ / pc.)
25.0376 € *
Available: 8 pcs.
Leadtime: 9 Weeks **
Total Price:
25.04 € *
Quantity
Price per unit*
1 pcs.
25.0376 €
5 pcs.
23.5382 €
15 pcs.
22.6338 €
50 pcs.
21.6342 €
150 pcs.
20.7298 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Sensor-actuator connector, 1619597, Phoenix Contact
Cable connector, CA, straight, SPEEDCON locking, M23, No. of pole: 8+1, Direction of rotation: Standard, type of contact: Socket, Solder connection, cable diameter range: 3 mm - 14.5 mm.
Features
- Shielded
- Connector for flexible on-site assembly
- Consistent EMC protection for reliable transmission of signals
- Solder connection: proven connection technology for various litz wires
- Circular connector
Technical specifications
| Version | socket | |
| Thread size | M23 | |
| Coding | N | |
| Contact connection | solder connection | |
| contact surface | gold-plated | |
| Assembly | cable assembly | |
| Orientation | straight | |
| Pin number | 9 pole | |
| Degree of protection (IP) | IP67 | |
| Type of locking | SPEEDCON locking |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
