1619541 | Phoenix Contact

Jack, M23, 17 pole, solder connection, SPEEDCON locking, straight, 1619541

Order No.: 62P0465
EAN: 4046356823159
MPN:
1619541
CA-17S1N128006S
Series: CA
1619541 Phoenix Contact Sensor-Actuator Connectors
Image may differ
Unit Price (€ / pc.)
38.556 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
38.56 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
38.556 €

Sensor-actuator connector, 1619541, Phoenix Contact

Cable connector, CA, straight, SPEEDCON locking, M23, No. of pole: 17, Direction of rotation: Standard, type of contact: Socket, Solder connection, cable diameter range: 4 mm - 6 mm.

Features

  • Shielded
  • Connector for flexible on-site assembly
  • Consistent EMC protection for reliable transmission of signals
  • Solder connection: proven connection technology for various litz wires
  • Circular connector
Technical specifications
Coding N
Type of locking SPEEDCON locking
Thread size M23
Degree of protection (IP) IP67
contact surface gold-plated
Orientation straight
Pin number 17 pole
Assembly cable assembly
Contact connection solder connection
Product type jack
Logistics
Customs tariff number 85366990
Country of origin DE
Compliance
RoHS conform Yes
SVHC free No
Date of RoHS guidelines 3/31/15
Substance description Lead
