1619005 | Phoenix Contact

Jack, M17, 8 pole, crimp connection, screw locking, straight, 1619005

Order No.: 62P4451
EAN: 4046356813891
MPN:
1619005
ST-08S1N8A8005
Series: ST
1619005 Phoenix Contact Sensor-Actuator Connectors
Image may differ
Unit Price (€ / pc.)
26.8702 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
26.87 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
26.8702 €

Sensor-actuator connector, 1619005, Phoenix Contact

Cable connector, straight, Screw locking, M17, number of positions: 8, type of contact: Socket, cable diameter range: 10 mm - 12.5 mm, number of positions: 8, connection method: Crimp connection.

Features

  • Shielded
  • Consistent EMC protection for reliable connection solutions in the industrial environment
  • N-coded
  • Overvoltage category: II
  • Degree of protection: IP67
  • Seal material: FPM

Applications

  • For signal applications
Technical specifications
Filter Property Value
Product type jack
Assembly cable assembly
Orientation straight
Coding N
Type of locking screw locking
Degree of protection (IP) IP67
Contact connection crimp connection
Pin number 8 pole
Thread size M17
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
SVHC free No
Substance description Lead
Date of RoHS guidelines 3/31/15
RoHS conform Yes
