1618708 | Phoenix Contact

Jack, M17, 7 pole, crimp connection, SPEEDCON locking, straight, 1618708

Order No.: 62P4686
EAN: 4046356809689
MPN:
1618708
ST-6ES1N8A9K02S
Series: ST
1618708 Phoenix Contact Sensor-Actuator Connectors
Image may differ
Unit Price (€ / pc.)
31.0709 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
31.07 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
31.0709 €

Coupler connector, 1618708, Phoenix Contact

Coupler connector, straight, for standard and SPEEDCON interlock, M17, number of positions: 6+PE, type of contact: Socket, cable diameter range: 3.5 mm - 5.5 mm, number of positions: 7, connection method: Crimp connection.

Features

  • Shielded
  • Consistent EMC protection for reliable connection solutions in the industrial environment
  • N-coded
  • Overvoltage category: III
  • Degree of protection: IP67
  • Seal material: FPM

Applications

  • For power applications
Technical specifications
Filter Property Value
Product type jack
Assembly cable assembly
Orientation straight
Coding N
Type of locking SPEEDCON locking
Degree of protection (IP) IP67
Contact connection crimp connection
Pin number 7 pole
Thread size M17
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
SVHC free No
Substance description Lead
Date of RoHS guidelines 3/31/15
RoHS conform Yes
